Sending money from one country to another sounds simple: you type in an amount, pick a destination, and press send. But hidden inside that single button press is one of the hardest problems in financial engineering — converting one currency into another, at a price that is constantly moving, while promising the customer that the price they saw is the price they get. This guide designs that system from the ground up, for a remittance company that might be sending money for a student paying college fees in Canada, a construction worker in the Gulf sending savings home to the Philippines, or a small business paying an overseas supplier.

Currency conversion itself is an old idea. Money changers have existed since ancient trade routes connected Rome, Persia, and China, physically swapping coins of different empires at rates they decided on the spot. The modern foreign exchange (FX) market, where currencies are traded electronically between banks, was born after 1971 when major currencies stopped being pegged to gold and started floating freely against each other. Since then, exchange rates move every second based on interest rates, trade flows, political events, and pure supply and demand. A rate that was true when you opened this article may already be stale by the time you finish reading this sentence.

Digital remittance companies such as Wise, Remitly, Xoom, and WorldRemit built their businesses on top of this constantly-moving market. Their core promise to a customer is trust: “the rate we show you is the rate you get.” Delivering on that promise while operating at global scale — potentially processing millions of quote requests every minute during peak events like salary day in the Gulf or festival season in South Asia — is a genuinely hard distributed systems problem, and it is exactly the kind of problem interviewers love to ask about because it touches consistency, caching, concurrency, financial correctness, and extreme scale all at once.

1.1 From wire transfers to real-time apps

For most of the 20th century, sending money abroad meant a bank-to-bank wire transfer through the SWIFT messaging network, a process that could take three to five business days and involved intermediary “correspondent” banks each taking a cut, with the exchange rate typically decided unilaterally by the sending bank and disclosed only after the fact. The first generation of digital remittance startups in the 2010s didn’t just move the same process onto a website — they rebuilt the pricing model itself, making the exchange rate visible and quoted upfront as a core product feature, which is what turned currency conversion from a back-office banking function into a customer-facing, real-time system that has to be fast, transparent, and provably honest.

1.2 Why this system matters for an architect

This is not a toy CRUD problem. A currency conversion engine sits at the intersection of five hard sub-problems that architects are expected to reason about together:

• Real-time data ingestion — pulling live FX rates from multiple providers, often tens of times per second per currency pair.
• Strong consistency for money — the rate quoted and the rate applied must be provably identical, not “close enough.”
• Extreme read scale — quote requests can be a much higher volume than actual transactions, since customers check rates repeatedly before deciding to send.
• Regulatory and audit requirements — every quote and every executed transaction must be logged immutably for compliance, tax, and dispute resolution.
• Global low latency — customers in India, Philippines, Kenya, Mexico, and the US all expect sub-second quote responses.

Let’s state the core problem precisely, because precision is what separates a strong system design answer from a vague one.

2.1 Why “just use the live rate” doesn’t work

A naive design fetches the current market rate at the exact moment the customer clicks “confirm” and applies it. This seems simple, but it breaks the fundamental promise: the number the customer approved and the number they get charged can differ, sometimes significantly during volatile market moments (a central bank rate announcement can move a currency pair by 1–2% in seconds). Customers experiencing “rate slippage” — a worse rate at execution than at quote time — lose trust immediately and often escalate to regulators, since remittance is a regulated financial service in almost every country.

2.2 Two real problems hiding inside one

When you unpack “show the rate and honor the rate,” you actually find two distinct engineering problems, and good candidates in an interview separate them explicitly:

2.3 Business constraints that shape the design

• Quote validity window: typically 15 to 60 seconds. Long enough for a customer to review, short enough that the company’s own currency risk exposure stays bounded (the company itself has to buy/sell currency in the wholesale FX market, and if the customer’s locked rate is stale relative to the real market, the company absorbs the difference).
• Margin / markup: the rate shown to the customer is the wholesale mid-market rate plus a margin (the company’s revenue). This margin calculation must also be locked along with the rate.
• Regulatory audit: regulators (like FinCEN in the US, FCA in the UK, RBI in India) require proof of what rate was quoted, when, and what was executed — often for 5–7 years.
• Idempotency: a customer’s app might retry a “confirm” call due to a flaky mobile network. The same locked quote must never be executed twice.
• Scale: during high-traffic windows (payday, festivals, market volatility spikes driving people to check rates repeatedly), the quote-fetching path can see enormous read traffic even though the actual money-moving transactions are a much smaller fraction of that traffic.

Before diving into individual pieces, here is the full system laid out end to end. Every box below names both its function and its role in the request path (gateway, load balancer, cache, queue, and so on), because in an interview it is not enough to draw circles — you must be able to say what kind of component each box is and why it sits where it sits.

3.1 Component-by-component breakdown

Let’s trace exactly what happens inside the system, component by component, for the two operations that matter most: getting a quote, and executing a transfer against that quote.

4.1 How a quote is built

1. Client sends GET /quotes?from=USD&to=INR&amount=1000 through the CDN and Load Balancer to the API Gateway.
2. API Gateway authenticates the request and forwards it to the Quote Service.
3. Quote Service reads the current mid-market rate for USD to INR from the Rate Cache — an in-memory read, typically under 2 milliseconds.
4. Quote Service applies markup logic: finalRate = midMarketRate * (1 - marginPercent) for the customer-facing sell rate (the exact formula depends on whether the company earns margin by marking the rate up or down, and can include tiered pricing).
5. Quote Service generates a unique quoteId (UUID) and computes an expiry timestamp (now + TTL, typically 15–60 seconds).
6. Quote Service calls Rate Lock Service to persist {quoteId, fromCurrency, toCurrency, sourceAmount, lockedRate, destinationAmount, expiresAt, customerId} into the Lock Store with a matching TTL.
7. Response returned to the client with the locked rate and a countdown timer for the UI.

4.2 How a transfer is executed against a locked quote

1. Client sends POST /transfers {quoteId, idempotencyKey}.
2. Transaction Orchestrator looks up quoteId in the Lock Store.
3. If the key is missing (expired or never existed), the orchestrator rejects with a specific QUOTE_EXPIRED error — never falls back to “just use current rate” silently.
4. If found, the orchestrator checks the idempotency key against a short-lived idempotency table to guard against duplicate submissions.
5. The orchestrator opens a distributed transaction workflow (often a saga) spanning: debit source account in Ledger Service, call Payment Execution Service to disburse in destination currency at the exact locked rate, and mark the quote as consumed (deleting it from the Lock Store to prevent replay even within the TTL window).
6. On success, a TransferExecuted event is published to Kafka containing the locked rate that was applied, alongside the original quoted rate for automated reconciliation.
7. Notification Service consumes the event and sends the customer a receipt confirming the exact rate — the customer-facing proof that quote and execution matched.

4.3 Idempotency: why it matters here specifically

Mobile networks are unreliable. A customer’s confirm tap might time out client-side and get retried automatically, even though the server actually processed it. Without idempotency protection, this could debit the customer twice for one transfer. The fix is a client-generated idempotency key stored alongside the transaction result for a window (typically 24 hours); if the same key arrives again, the orchestrator returns the original result instead of re-executing.

public TransferResult executeTransfer(String quoteId, String idempotencyKey) {

    Optional<TransferResult> existing = idempotencyStore.find(idempotencyKey);
    if (existing.isPresent()) {
        // Same request seen before - return original outcome, do not re-execute
        return existing.get();
    }

    LockedQuote quote = lockStore.get(quoteId)
        .orElseThrow(() -> new QuoteExpiredException(quoteId));

    // Atomically claim the quote so two concurrent requests can never
    // both execute against the same quoteId (Redis GETDEL semantics)
    boolean claimed = lockStore.deleteIfPresent(quoteId);
    if (!claimed) {
        throw new QuoteAlreadyConsumedException(quoteId);
    }

    TransferResult result = runTransferSaga(quote);
    idempotencyStore.save(idempotencyKey, result, Duration.ofHours(24));
    return result;
}

Notice the deleteIfPresent call: this is doing double duty. It reads the locked quote and atomically removes it in one operation (Redis’s GETDEL command, for example), so that if two requests race to consume the same quoteId — say, a retried request arriving a few milliseconds after the original — only one of them can win the claim. The other gets a clean, explicit error instead of silently re-executing.

4.4 Rate ingestion internals

Rate Ingestion Workers subscribe to multiple external providers in parallel (never just one — see Section 8 on HA). Each incoming rate update goes through a sanity filter before being trusted:

public boolean isRateSane(CurrencyPair pair, BigDecimal newRate) {
    BigDecimal previousRate = rateCache.getLastAccepted(pair);
    if (previousRate == null) {
        return true; // first rate seen for this pair, accept it
    }

    BigDecimal percentChange = newRate.subtract(previousRate)
        .abs()
        .divide(previousRate, 6, RoundingMode.HALF_UP);

    // Reject implausible single-tick jumps (likely a bad feed),
    // route to alerting and fall back to the secondary provider
    return percentChange.compareTo(MAX_ALLOWED_TICK_DEVIATION) <= 0;
}

4.5 Double-entry ledger internals

The Ledger Service never records a single number like “customer sent $1000.” Following standard double-entry accounting, every transfer produces at least two balanced entries — a debit and a credit — so the books always sum to zero and any single missing or duplicated entry is immediately detectable.

@Transactional
public void recordTransfer(LockedQuote quote, String transferId) {
    LedgerEntry debit = LedgerEntry.builder()
        .transferId(transferId)
        .account(quote.getCustomerSourceAccount())
        .currency(quote.getFromCurrency())
        .amount(quote.getSourceAmount().negate())
        .rateApplied(quote.getLockedRate())
        .build();

    LedgerEntry credit = LedgerEntry.builder()
        .transferId(transferId)
        .account(quote.getDestinationPayoutAccount())
        .currency(quote.getToCurrency())
        .amount(quote.getDestinationAmount())
        .rateApplied(quote.getLockedRate())
        .build();

    ledgerRepository.saveAll(List.of(debit, credit));
    // Both rows commit together or not at all - the ledger can never
    // be left in a half-written, unbalanced state.
}

4.6 CAP theorem: where each store sits

Every distributed component in this design makes a deliberate, explicit choice about where it sits on the CAP spectrum. Partition tolerance is non-negotiable in any real distributed system, making the practical choice really about consistency versus availability during a partition:

4.7 Concurrency control

The Lock Store’s atomic claim-and-delete operation is a form of optimistic concurrency control: rather than acquiring a heavyweight distributed lock before every read, the system lets many readers check a quote freely, and only enforces exclusivity at the single moment of consumption, using an atomic primitive provided by the store itself (Redis’s single-threaded command execution model guarantees that GETDEL cannot be interleaved with another client’s identical call on the same key). This keeps the hot read path completely lock-free while still guaranteeing exactly-once consumption at execution time.

4.8 Consensus for multi-node coordination

Where the system does need strict agreement across nodes — for example, Redis Cluster’s own decision about which node currently holds a given shard, or a Kafka partition’s leader election — the underlying infrastructure relies on established consensus protocols (Raft in Redis Cluster’s newer implementations, ZooKeeper / KRaft-based consensus in Kafka) rather than the application layer reinventing distributed consensus, which is a common and costly mistake in system designs at this level of complexity.

Two diagrams capture the lifecycle best: a sequence diagram showing the interaction between components across a full quote-to-settlement journey, and a state diagram showing the states a single quote or transaction moves through.

5.1 Reconciliation: closing the loop

Even with a correct design, financial systems run continuous reconciliation as a defense-in-depth measure. A background job periodically compares the rate recorded in the Audit Log for each executed transaction against the rate recorded in the Ledger entry — if the platform ever has a bug that lets these two drift, the reconciliation job catches it before a customer or regulator does.

6.1 Key trade-off: TTL length

6.2 Key trade-off: cache freshness versus provider load

Refreshing the Rate Cache more frequently keeps quotes closer to the true market price but increases load and cost on external FX data providers (many charge per API call or per data feed connection). Most production systems settle on continuous streaming subscriptions (push, not poll) for major pairs and a slower polling cadence for exotic, low-volume currency pairs.

A million requests per minute is roughly 16,700 requests/second sustained, and real traffic is never flat — expect 3–5x bursts around payday clusters, market volatility events, or marketing campaigns, so the system should be designed to comfortably absorb 50,000–80,000 requests/second at peak on the quote-read path specifically, since quote reads dominate total volume (customers check rates far more often than they actually transfer).

7.1 Read/write split is the foundation

The single most important scaling decision is recognizing that quote reads and transfer writes have wildly different volumes and different consistency needs, and must be scaled as separate pools:

7.2 Caching is what makes a million requests per minute feasible

The Quote Service must never call an external FX provider synchronously on the customer’s request path. Every quote request is served from the in-memory Rate Cache, which is refreshed asynchronously by the Rate Ingestion Workers independent of customer traffic. This converts an otherwise-impossible fan-out (millions of customer requests each needing a fresh external FX API call) into a simple in-memory lookup, decoupled entirely from external provider rate limits.

7.3 Horizontal scaling of the Quote Service

Because Quote Service instances are stateless (all state — the current rate — lives in the shared Rate Cache, and the resulting lock lives in the shared Lock Store), the service can be scaled horizontally behind the load balancer with no coordination needed between instances. Auto-scaling groups driven by CPU or request-latency metrics can add capacity in seconds to absorb bursts.

public Quote generateQuote(QuoteRequest request) {
    Rate rate = rateCache.getCurrentRate(request.getCurrencyPair()); // O(1) in-memory read
    BigDecimal lockedRate = pricingEngine.applyMargin(rate, request);
    String quoteId = UUID.randomUUID().toString();
    Instant expiresAt = Instant.now().plus(quoteTtl);

    LockedQuote lockedQuote = new LockedQuote(
        quoteId, request.getFrom(), request.getTo(),
        request.getAmount(), lockedRate, expiresAt, request.getCustomerId()
    );

    lockStore.put(quoteId, lockedQuote, quoteTtl); // single network hop, no local state kept

    return Quote.from(lockedQuote);
}

7.4 Rate Cache must be partitioned and replicated

A single Redis node cannot serve tens of thousands of reads per second from every regional pool reliably. The standard approach:

• Redis Cluster with sharding by currency pair (there are only a few hundred meaningful pairs, so this is a small, well-known key space — ideal for full replication rather than sharding by hash, since every shard can hold the entire rate table cheaply).
• Read replicas per region — since exchange rates are the same globally at a given instant, the Rate Cache can be replicated to every geographic region so a customer in Manila reads from a cache physically near them, not round-tripping to a single central cluster.
• Local in-process cache with a very short TTL (hundreds of milliseconds) as an optional extra layer inside each Quote Service instance, shaving off even the Redis network hop for the highest-traffic pairs, at the cost of very slightly staler data.

7.5 Rate limiting and backpressure

At this scale, some traffic will be abusive (bots scraping rates, competitor price-monitoring) or simply excessive. The API Gateway enforces per-customer and per-IP rate limits using a token bucket algorithm, protecting the Quote Service pool for genuine users.

public boolean allowRequest(String clientKey) {
    Bucket bucket = buckets.computeIfAbsent(clientKey,
        k -> Bucket.builder()
            .addLimit(Bandwidth.classic(100, Refill.greedy(100, Duration.ofSeconds(60))))
            .build());
    return bucket.tryConsume(1);
}

7.6 Asynchronous, queue-backed writes for the transfer path

While the transfer path is a much smaller fraction of overall volume, it still needs to handle real spikes (a payday moment where a huge fraction of confirmed quotes execute within the same minute). The orchestrator publishes execution requests onto Kafka partitioned by customer ID, letting downstream payment execution workers scale horizontally and process the queue at whatever rate the payment rails can sustain, smoothing bursts instead of overwhelming the payment provider’s own APIs.

7.7 Capacity math walkthrough

It helps to work the numbers concretely rather than treating “a million requests a minute” as an abstract phrase. The average rate resolves to $1{,}000{,}000 / 60 approx 16{,}667$ requests per second, and applying a peak factor of $3times$ to $5times$ pushes the design target to roughly $50{,}000$ to $85{,}000$ requests per second.

• Sustained load: 1,000,000 requests / 60 seconds ≈ 16,667 requests/second average.
• Peak burst factor: real-world traffic on payday or during a viral marketing moment can spike 3–5x above average for short windows, so the system should be provisioned (or able to auto-scale within seconds) to roughly 50,000–85,000 requests/second.
• Read/write split: if 95% of requests are quote reads, that’s ~47,500–80,000 reads/second against the Rate Cache, and only ~2,500–4,000 writes/second against the Lock Store and downstream execution path at peak — a very different scaling target for each store.
• Per-instance capacity: if a single Quote Service instance (a modest container, a few CPU cores) can sustain roughly 2,000–3,000 requests/second doing a pure in-memory cache read plus a lightweight lock write, the fleet needs on the order of 20–30 instances at peak — a small, very achievable number once the design has correctly removed all synchronous external calls from the hot path.

This kind of back-of-envelope math is exactly what interviewers want to see: not memorized numbers, but the ability to reason from a stated requirement down to a concrete instance count and identify which store needs the most headroom.

7.8 Capacity planning table

7.9 Networking considerations at this volume

Raw request-per-second numbers only tell part of the story; the networking layer itself needs deliberate tuning at this scale:

• HTTP/2 (or HTTP/3 where supported) between clients and the gateway multiplexes many logical requests over a single TCP connection, dramatically cutting connection-setup overhead versus HTTP/1.1 when a mobile app is polling for rate updates or a countdown timer.
• Connection pooling and keep-alive between internal services (Gateway to Quote Service, Quote Service to Redis) avoids the cost of a fresh TCP and TLS handshake on every internal call — at tens of thousands of requests per second, handshake overhead alone can become a dominant cost if connections aren’t reused.
• DNS-based global traffic routing (GeoDNS or anycast) sends a customer’s request to the nearest healthy region automatically, which both reduces latency and naturally load-balances traffic across regions without any single global load balancer becoming a bottleneck.
• gRPC for internal service-to-service calls (Quote Service to Rate Cache client, Orchestrator to Ledger Service) is a common choice over REST/JSON internally, since binary serialization and HTTP/2 multiplexing meaningfully reduce per-call overhead at this request volume, even though the customer-facing API remains REST/JSON for broad client compatibility.

8.1 No single FX provider

An outage or bad data tick from one FX rate provider must not take down the whole system. Rate Ingestion Workers subscribe to at least two independent providers per major currency pair; if the primary feed goes silent (no update within an expected heartbeat window) or produces a rate that fails the sanity check from Section 4.4, ingestion automatically fails over to the secondary provider, and an alert fires for the operations team.

8.2 Redis Cluster failover

Both the Rate Cache and the Lock Store run as multi-node clusters with replicas. If a primary node fails, a replica is promoted automatically (Redis Sentinel or Redis Cluster’s native failover) within seconds. Because the Rate Cache is a derived, refreshable value (it can be rebuilt from the next provider tick), losing it briefly is far less damaging than losing the Lock Store, which holds customer-facing promises — so the Lock Store is configured with a higher replication factor and, where the provider supports it, cross-AZ synchronous replication for the lock write itself.

8.3 Multi-region deployment

The entire stack (gateway, quote service, caches, orchestrator) is deployed across at least two geographic regions with active-active or active-passive routing via global DNS/traffic manager. A regional outage fails traffic over to the healthy region. The one subtlety: a lock created in Region A must be visible to an execution request that lands in Region B (possible if a customer’s network path changes mid-session), which is why the Lock Store typically uses a globally-replicated data store or sticky regional routing keyed by customer session for the life of a single quote.

8.4 Graceful degradation

If the Rate Cache becomes fully unavailable in a worst-case scenario, the system should fail closed on new quotes (show “rates temporarily unavailable” rather than serving a stale or guessed rate) while still allowing already-locked, in-flight transactions to complete using their existing lock — the two failure domains are handled differently on purpose.

8.5 Circuit breakers around external dependencies

public PaymentResult executePayment(PaymentRequest request) {
    if (circuitBreaker.isOpen("payoutProviderX")) {
        return payoutRouter.routeToBackupProvider(request);
    }
    try {
        PaymentResult result = payoutProviderXClient.send(request);
        circuitBreaker.recordSuccess("payoutProviderX");
        return result;
    } catch (ProviderTimeoutException e) {
        circuitBreaker.recordFailure("payoutProviderX");
        return payoutRouter.routeToBackupProvider(request);
    }
}

8.6 Disaster recovery

The Ledger and Audit stores, being the systems of record, are backed up continuously (write-ahead log shipping to a secondary region) with a target Recovery Point Objective (RPO) close to zero and a Recovery Time Objective (RTO) measured in minutes — financial regulators typically require both to be documented and tested.

9.1 Authentication & authorization

Every request is authenticated via OAuth 2.0 / JWT at the API Gateway. Fine-grained authorization ensures a customer can only lock and execute quotes tied to their own account, enforced server-side on every call, never trusted from client-supplied identifiers.

9.2 Protecting the rate and lock APIs

• Tamper-proof quoteId: IDs are cryptographically random UUIDs, not sequential integers, so a customer cannot guess or enumerate another customer’s active quote.
• Server-side rate application only: the client never sends a rate value to the server; it only ever sends a quoteId, and the server looks up the authoritative locked rate itself. This closes off an entire class of client-side tampering attacks where a malicious client could otherwise submit a favorable rate directly.
• mTLS between internal services (Quote Service, Orchestrator, Ledger, Payment Execution) so that even inside the private network, services authenticate each other.

9.3 Fraud & AML controls

Before a locked quote can be executed, the orchestrator checks the customer’s KYC/AML status and runs the transaction through sanctions-list screening and velocity checks (unusual transfer patterns), consistent with global anti-money-laundering regulation. High-risk transactions are held for manual review rather than auto-executed.

9.4 Data protection

Customer PII and payment credentials are encrypted at rest (AES-256) and in transit (TLS 1.3). Sensitive fields in logs (account numbers, full names) are masked before reaching the centralized logging system, since logs are a common accidental leak vector.

9.5 Secrets management

Credentials for FX data providers and payment rails are stored in a dedicated secrets manager (HashiCorp Vault or a cloud KMS-backed secret store) with short-lived, automatically rotated credentials rather than long-lived static API keys embedded in configuration.

9.6 Preventing replay and double-spend

Covered in depth in Section 4.3 — the atomic claim-and-delete on the Lock Store plus idempotency keys together close the two realistic replay vectors: a client retry, and a malicious actor attempting to resubmit a captured request.

10.1 The metrics that matter most for this system

10.2 Distributed tracing

Every request carries a correlation ID (propagated via OpenTelemetry) from the API Gateway through Quote Service, Rate Cache, Lock Store, and — for executed transfers — through the Orchestrator, Ledger, and Payment Execution Service. This lets an engineer reconstruct the full path of a single customer’s transfer in seconds when investigating a support ticket, rather than grepping logs across a dozen services manually.

10.3 Alerting philosophy

Alerts are tiered by business impact, not just technical severity:

• P1 (page immediately): lock-to-execution rate mismatch detected; Lock Store cluster degraded; payment execution error rate above threshold.
• P2 (urgent, business hours): a single FX provider feed down (system still healthy via failover, but risk elevated); elevated quote expiry rate.
• P3 (informational): auto-scaling events, minor latency degradation within SLA.

10.4 Dashboards for different audiences

Engineering dashboards track latency and error budgets. A separate finance/risk dashboard tracks aggregate FX exposure (sum of all currently-locked, unexecuted quote amounts per currency pair) in near real time, since that number represents the company’s live financial risk at any given moment.

11.1 Containerized microservices on Kubernetes

Each service (Quote Service, Rate Ingestion Workers, Transaction Orchestrator, Ledger Service, Payment Execution Service, Notification Service) is packaged as an independent container and deployed on Kubernetes, letting each be scaled, deployed, and rolled back independently based on its own traffic profile — the Quote Service pool, for instance, needs far more replicas than the Ledger Service pool.

11.2 Blue-green and canary deployments

Given the financial stakes, changes to the Quote Service or Transaction Orchestrator are rolled out via canary deployment: a small percentage of traffic (5%) is routed to the new version while automated checks confirm the lock-to-execution mismatch metric from Section 10.1 stays at zero before the rollout proceeds further. Any anomaly triggers automatic rollback.

11.3 Infrastructure as code

The entire environment — Kubernetes clusters, Redis clusters, Kafka topics, database instances, networking, and IAM policies — is defined declaratively (Terraform or similar) so that a new region can be stood up reproducibly, which matters both for disaster recovery and for expanding into new remittance corridors.

11.4 Multi-region cloud topology

A common pattern is regional active-active deployment: US, EU, and APAC regions each run a full stack, with the Rate Cache replicated globally (rates are the same everywhere at a given instant) and customer data/ledger sharded regionally to satisfy data residency regulations that many countries impose on financial data.

11.5 Cost optimization

The Quote Service pool, being stateless and bursty, is a good candidate for spot/preemptible instances mixed with a baseline of reserved capacity, since a terminated instance simply drops out of the load balancer pool with no data loss. The Ledger and Lock Store tiers, by contrast, run on stable, reserved infrastructure given their correctness sensitivity.

12.1 Choosing the database for each store

12.2 Caching strategy deep dive

The Rate Cache uses a write-through pattern from the Rate Ingestion Workers (the workers are the only writers; the Quote Service pool only ever reads). This avoids the classic cache-invalidation complexity that arises when many independent services all try to write to a shared cache — here, there is exactly one writer role, which drastically simplifies correctness.

12.3 Load balancing algorithms

• Layer 4 (network) load balancing at the outermost edge for raw connection distribution across regions, using least-connections or consistent-hashing algorithms.
• Layer 7 (application) load balancing at the API Gateway tier, which can route based on request path (separating quote traffic from execution traffic onto differently-sized backend pools) and perform active health checks, pulling an unhealthy Quote Service instance out of rotation within seconds.
• Client-side load balancing between internal services (Orchestrator to Ledger Service) via a service mesh (Istio/Linkerd), which also provides mTLS and fine-grained traffic shaping for canary releases.

12.4 Sharding the primary database

Customer transaction history is sharded by a hash of customer ID combined with home region, which keeps each customer’s queries local to one shard (avoiding cross-shard joins for the common case of “show me my transaction history”) while distributing write load evenly across the cluster as the customer base grows.

13.1 Core API contract

POST /v1/quotes
Request:  { "fromCurrency": "USD", "toCurrency": "INR", "sourceAmount": 1000.00 }
Response: {
  "quoteId": "8f14e45f-ceea-4c7f-b1ab-3c6d1c2e9a11",
  "fromCurrency": "USD",
  "toCurrency": "INR",
  "lockedRate": 83.42,
  "sourceAmount": 1000.00,
  "destinationAmount": 83420.00,
  "expiresAt": "2026-08-04T10:15:45Z"
}

POST /v1/transfers
Headers:  Idempotency-Key: <client-generated-uuid>
Request:  { "quoteId": "8f14e45f-ceea-4c7f-b1ab-3c6d1c2e9a11" }
Response: {
  "transferId": "b2f9...",
  "status": "SETTLED",
  "appliedRate": 83.42,
  "destinationAmount": 83420.00
}

Notice that the applied rate returned from the Transfer API is expected to always exactly equal the locked rate from the original Quote API response — this equality is, in effect, the single most important test case in the entire system’s test suite.

13.2 Why microservices (and where the boundaries are)

The service boundaries in Section 3 are drawn along two principles: differing scaling needs (Quote Service scales very differently from the Ledger Service) and differing consistency needs (the Rate Ingestion path can tolerate eventual consistency; the Orchestrator and Ledger cannot). Splitting along these lines lets each team own a service with a genuinely distinct operational profile, rather than splitting arbitrarily by “noun” (which often produces services that must be deployed and scaled in lockstep anyway).

13.3 Synchronous versus asynchronous communication

13.4 API versioning and backward compatibility

Given how many partner integrations may depend on this API, all breaking changes go through explicit versioning (/v1/, /v2/) with a long deprecation window, and additive fields are always optional in responses so existing integrations don’t break silently.

14.1 Patterns used in this system

14.2 Anti-patterns to avoid

15.1 Best practices

• Always check quote expiry server-side, never trust a client-reported countdown timer.
• Make the locked rate immutable once written — no update operations on a Lock Store entry, only create and atomic delete-on-consume.
• Log the source FX provider and exact ingestion timestamp alongside every rate, so any dispute can be traced back to the raw market data that produced it.
• Treat quote-rate-equals-applied-rate as an automated, continuously-running invariant check, not just a one-time test at launch.
• Design margin/markup logic as a pure, versioned function so past quotes can always be recalculated exactly as they were computed at the time, for audit purposes.
• Separate the “read-mostly, cache-friendly” quote path from the “write-heavy, consistency-critical” execution path at every layer — service, database, and even on-call rotation.

15.2 Common mistakes

• Under-provisioning the Lock Store: teams often size Redis for the Rate Cache’s read load and forget the Lock Store needs write throughput matching peak quote-generation volume, not transfer volume.
• Treating TTL expiry as best-effort: relying purely on Redis’s TTL eviction without also validating expiry explicitly in application logic during a network partition or clock-skew edge case.
• Ignoring corridor-specific volatility when setting a single global TTL and margin for every currency pair, which under-prices risk on volatile pairs and over-prices it on stable ones.
• Skipping load testing the Lock Store specifically — teams often load-test the Quote Service’s read path thoroughly but under-test the write-heavy lock-and-claim path, which behaves very differently under contention.
• Rounding rates and amounts inconsistently between services: if the Quote Service and the Ledger Service round a converted amount using different decimal precision or rounding modes, the two can disagree by a fraction of a currency unit — small individually, but a real regulatory and reconciliation problem in aggregate across millions of transactions, so rounding rules must be defined once, centrally, and applied identically everywhere.

15.3 A simple rule of thumb

Several well-known companies have publicly discussed pieces of how they approach this exact problem, and the patterns above map closely onto their public engineering narratives.

17.1 The one idea to remember

If you take one architectural lesson from this guide into your next system design interview or your own production system, let it be this: separate the parts of your system that are allowed to change from the parts that must never change once promised. A live market rate is allowed to change every second — that’s the Rate Cache’s whole job. A rate shown to a specific customer, tied to a specific quoteId, must become frozen and immutable the instant it is shown — that’s the Rate Lock Store’s whole job. Almost every design decision in this document, from the choice of database, to the TTL trade-off, to the CAP-theorem posture of each component, to the anti-patterns worth memorizing, falls directly out of keeping those two responsibilities cleanly separated and never letting one leak into the other.
